HF

In-Line Flow Monitors / For Air, Water or Caustic Fluids, Unrestricted Mounting, High Temperature and Pressure Options. Ranges : 2 to 22 SCFM air; 0.5 to 25 GPM oil; 0.05 to 116 GPM water. Accuracy : ±4% FS. Process Connection : 1/8˝ to 2˝ female NPT back connections. Scale Length : 1-1/2˝ to 2-1/4˝ (38 to 57 mm).

IF

IF Industrial Direct Reading Flowmeters / Air/Water Direct Reading Scale, 304 SS Protective Shield. Ranges : 1.2 to 250 SCFM air (35 to 7080 LPM air); 0.25 to 116 GPM water (0.95 to 439 LPM water). Accuracy : ±3% FS. Process Connection : 1/2˝, 1˝ or 2˝ female NPT back connections. Scale Length : 4-3/4˝ (120 mm).

DR20000

Direct Reading Glass Flowmeters. Ranges : 0.33 to 90 SCFH air (0.16 to 44 LPM air) 0.05 to 21 GPH water (3.2 to 1300 cc/m water). Accuracy : ±5% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 6˝(150 mm).

DR10000

Direct Reading Glass Flowmeters. Ranges : 0.24 to 100 SCFH air (0.13 to 50 LPM air) 0.02 to 24 GPH water (1.5 to 1500 cc/m water). Accuracy : ±5% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 2.5˝ (65 mm).

VA25000

PTFE Variable Area Glass Flowmeters / Interchangeable Flowtubes, Universal mm. Ranges : 0.104 to 18.39 SCFH air (49 to 8600 ml/m air) 0.01 to 3.32 GPH water (0.61 to 209 ml/min water). Accuracy : ±2% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 6˝ (150 mm).

VA20000

Metal Variable Area Glass Flowmeters / Interchangeable Flowtubes, Universal mm. Ranges : 0.792 to 93.9 SCFH air (374 to 44300 ml/min air) 0.087 to 21.7 GPH water (5.5 to 1370 ml/m water). Accuracy : ±2% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 6˝ (150 mm).

VA1500

PTFE Variable Area Glass Flowmeters / Interchangeable Flowtubes, Universal mm Scale. Ranges : 0.22 to 49 SCFH air (104 to 23100 ml/min air) 0.028 to 27 GPH water (1.8 to 522 ml/min water). Accuracy : ±2% FS. Process Connection : 1/8˝female
NPT back connections. Scale Length : 2.5˝(65 mm).

VA1000

Metal Variable Area Glass Flowmeters / Interchangeable Flowtubes, Universal mm Scale. Ranges : 0.104 to 89.2 SCFH air (49 to 42000
ml/m air) 0.009 to 19.97 GPH water (0.55 to 1260 ml/m water). Accuracy : ±2% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 2.5˝(65 mm).

TVA

All Fluoropolymer Flowmeters / 75 mm and 125 mm, 10:1 Turndown, Back Connect, Corrosive Resistant. Ranges : 6.34 to 79.2 GPH water (400
to 5000 ml/min water). Accuracy : ±5% FS.
Process Connection : 1/4˝ or 3/8˝female NPT back connections. Scale Length : 3˝(75 mm).

VAT

Variable Area Fluoropolymer Flowmeters / In-Line, Chemically Inert. Ranges : 1.19 to 79 GPH water (75 to 5000 ml/min water). Accuracy : ±5% FS. Process Connection : 1/4˝ or 3/8˝female NPT back connections. Scale Length : 5˝ (127 mm).

LFMF

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 2.5 to 70 GPM water (10 to 250 LPM water). Accuracy : ±5% FS. Process Connection : 2˝ male or female NPT in-line connections. Scale Length : 5.5˝(140 mm).

LFME

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 1.2 to 25 GPM water (5 to 100 LPM water). Accuracy : ±5% FS. Process Connection : 1˝ male or female NPT in-line or 1˝male NPT 90° elbow connections. Scale Length : 4.5˝(114 mm).

LFMD

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 0.8 to 10 GPM water(3 to 40 LPM water). Accuracy : ±5% FS. Process Connection : 3/4˝ male or female NPT in-line or 3/4˝ male NPT 90° elbow connections. Scale Length :3.5˝(89 mm).

LFMC

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 0.25 to 8 GPM water (1 to 30 LPM water). Accuracy : ±5% FS. Process Connection : 1/2˝ or 3/4˝ male NPT in-line or 1/2˝ male NPT 90° elbow connections. Scale Length : 3˝(76 mm).

LFMB

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 0.1 to 5 GPM water
(0.5 to 18 LPM water). Accuracy : ±5% FS. Process Connection : 1/2˝ male NPT in-line or 90° elbow connections. Scale Length : 3˝(76 mm).

LFMA

Polycarbonate Flowmeters / Chemically Resistant, In-Line or Panel Mount Options, Adjustable Set Point Indicator Option. Ranges : 0.1 to 5 GPM water (0.5 to 18 LPM water). Accuracy : ±5% FS. Process Connection : 1/2˝ male NPT in-line or 90° elbow connections. Scale Length : 2˝(51 mm).

VFC

Visi-Float® Acrylic Flowmeter / Hot-Stamped Scales, Multi-Angle Views of Flow. Ranges : 2.5 to 100 SCFM air (60 to 2800 LPM air); 0.5 to 20 GPM water
(2 to 75 LPM water). Accuracy : ±2% FS. Process Connection : 1˝ female or male NPT
or BSPT back or end
connections. Scale Length : 5"(127 mm).

VFB

Visi-Float® Acrylic Flowmeter / Hot-Stamped Scales, Multi-Angle Views of Flow. Ranges : 0.3 to 200 SCFH air (0.2 to 40 LPM air); 0.5 GPH to 5 GPM water (0.002 to 20 LPM water). Accuracy : ±3% FS. Process Connection : 1/8˝ female NPT back or end connections. Scale Length : 4˝(102 mm).

VFA

Visi-Float® Acrylic Flowmeter / Hot-Stamped Scales, Multi-Angle Views of Flow. Ranges : 0.1 to 200 SCFH air (0.06 to 100 LPM air); 0.6 to 40 GPH water (6 to 200 cc/m water). Accuracy : ±5% FS. Process Connection : 1/8˝ female NPT back or end connections. Scale Length : 2" (51 mm).

RMC

Rate-Master® Polycarbonate Flowmeter. Ranges : 0.1 to 200 SCFH air (0.06 to 100 LPM air); 0.6 to 40 GPH water (6 to 200 cc/m water). Accuracy : ±2% FS. Process Connection : 1/2˝ female NPT back connections. Scale Length : 10˝ (254 mm).

RMB

Rate-Master® Polycarbonate Flowmeter. Ranges : 0.5 to 600 SCFH air (0.6 to 95 LPM air); 1 to 100 GPH water (0.06 to 6.2 LPM water). Accuracy : ±3% FS. Process Connection : 1/4˝ female NPT back connections. Scale Length : 5˝(127 mm).

RMA

Rate-Master® Polycarbonate Flowmeter. Ranges : 0.05 to 200 SCFH air (5 to 2500 cc/m air); 1 to 50 GPH water (5 to 300 cc/m water). Accuracy : ±4% FS. Process Connection : 1/8˝ female NPT back connections. Scale Length : 2˝ (51 mm)
